3/2 Solenoid Valve Specifications Specification Value Electrical connection M27 x 1 Exhaust 2.2 mm Max. operating pressure 12.5 bar Multi nominal diameter (from port 1 to x) 2.2 mm Nominal...
3/2 Solenoid Valve
Specifications
| Specification | Value |
| Electrical connection | M27 x 1 |
| Exhaust | 2.2 mm |
| Max. operating pressure | 12.5 bar |
| Multi nominal diameter (from port 1 to x) | 2.2 mm |
| Nominal diameter | 2.2 mm |
| Port thread 1 | M12 x 1.5 |
| Port thread 2 | M12 x 1.5 |
| Port threads | M12 x 1.5 |
| Protection class | IP 6K6, IP 6K9K |
| Rated current | 410 mA |
| Temperature range | -40°C to +80°C |
| Type | Normally closed |
| Voltage | 24 V |
| Size (mm x mm x mm) | 116 x 62 x 40 |
| Weight (kg) | 0.54 |
| Weight (lb) | 1.1905 |
Cross References
| Replaces | Part Number |
| Alexander Dennis | 658072 |
| DAF | 1327108 |
| DAF | 867177 |
| DAF | 867177 |
| Evobus | 82855460000 |
| Evobus | A0009970712 |
| Feldbinder | 1847 |
| Freightliner | TDA2S4721726000 |
| Irisbus | 41016830 |
| Iveco | 41016830 |
| Iveco | 42320501 |
| Iveco | 4752910 |
| Iveco | 4818960 |
| Kenworth | S4721726000 |
| Komatsu | 65400240 |
| Liebherr | 502659608 |
| Liebherr | 502985201 |
| Liebherr | 502814501 |
| Mack | 6300-4721726000 |
| Mercedes-Benz | 9970712 |
| Mercedes-Benz | A0009970712 |
| Mercedes-Benz | A6623200358 |
| Mercedes-Benz | A0039971136 |
| Meritor | S4721726000 |
| Neoplan | 11017370 |
| Nooteboom | 1157544 |
| Nooteboom | 4031615 |
| Paccar | 0865680R |
| Peterbilt | S4721726000 |
| Renault | 5001843881 |
| Renault | 5010376941 |
| Renault | 5021170194 |
| Scania | 1934962 |
| Schmitz Cargobull | 50805 |
| Schmitz Cargobull | 50805 |
| Schmitz Cargobull | INSO120005 |
| Schmitz Cargobull | INS0120005 |
| Schwarzmãœller | 35176 |
| Solaris | 1102540010 |
| Terex | 65400240 |
| VDL | 25100256000 |
| VDL | 20190351 |
| VDL | 190351 |
| Volvo | S4721726000 |
| Volvo | S472 172 600 0 |
| Volvo | WAB4721726000 |
| Yutong | 350600709 |
| Yutong | 3506-00709 |
| Zorzi | 1013004 |
Repair Kits
| Part Number | Description |
| PSV/72/111 | Kit: Cap |
