Tristop-Cylinder Cam F-27/30
Specifications
| Specification | Value |
| Bolt Lengths | 33.0 mm |
| Bolt Threads | 2 x M16 x 1.5 |
| Distance Between Bolts | 120.6 mm |
| Max. Operating Pressure | 10.2/8.5 bar |
| Output Force | 311000 N |
| Output Force m | 9800 N |
| Port Thread 11 | M16 x 1.5 |
| Port Thread 12 | M16 x 1.5 |
| Port Threads | M16 x 1.5 |
| Push-rod Length | 50.8 mm |
| Push-rod Thread | M14 x 1.5 |
| Release Pressure | 5.1 bar |
| Return-spring Force | 250 N |
| Stroke | 64/64 mm |
| Temperature Range | -40°C to +80°C |
| Thread Length | 35 mm |
| Total Length | 283.0 mm |
| Type | 27/30 |
| Type of Operation | Cam |
| Version | Without boot |
| Yoke | No |
| Size (mm x mm x mm) | 220 x 220 x 480 |
| Weight (kg) | 11.66 |
| Weight (lb) | 25.7059 |
Cross References
| Replaces | Part Number |
| Alexander Dennis | DP002101 |
| DAF | 1192712 |
| DAF | 1245769 |
| DAF | 1525513 |
| Paccar | 1525513 |
| VDL | 4.12E+07 |
| VDL | 1192712 |
Repair Kits
| Part Number | Description |
| PSV/74/726 | Kit: Diaphragm + Hose Coupling |
| PSV/74/727 | Kit: Diaphragm + Hose Coupling |
