Solenoid Valve 2/2
Specifications
| Specification | Value |
| Cooling | Air |
| Electrical connection | Bayonet DIN 72 585 A1-2.1-Sn/K1 |
| Max. operating pressure | 16.0 bar |
| Multi nominal diameter | 2.2 mm (from port 1 to x) |
| Nominal diameter | 2.2 mm |
| Port thread 1 | M10 x 1 |
| Port thread 2 | M12 x 1.5 |
| Port thread 3 | M12 x 1.5 |
| Protection class | IP 6K9K, IP 6K7 |
| Rated current | 410 mA |
| Temperature range | -40°C to +80°C |
| Type | Normally open |
| Voltage | 24 V |
| Size (L x W x H) | 39 x 123 x 63 mm |
| Weight | 0.556 kg (1.2258 lb) |
Cross References
| Replaces | Part Number |
| DAF | 1330135 |
| Leyland DAF | 1.33E+06 |
| Scania | 1934972 |
