Single Chamber Air Dryer
Specifications
| Specification | Value |
| Cartridge Type | Desiccant Cartridge |
| Comments | Turbo-cut-off valve installed |
| Cut-out Pressure | 10 bar |
| Opening Pressure | 12.00 bar |
| Operational Range | 0.7 bar |
| Max. Operating Pressure | 10.0 bar |
| Heating Connection | Kostal M27 x 1 |
| Voltage | 24 V |
| Unloader | No |
| Port Thread 1 | M22 x 1.5 |
| Port Thread 21 | M22 x 1.5 |
| Port Thread 22 | M12 x 1.5 |
| Port Thread 4/23 | 1/4" - 18 NPTF |
| Size (mm x mm x mm) | 280 x 140 x 140 |
| Weight (kg) | 3.99 |
| Weight (lb) | 8.7964 |
Cross References
| Replaces | Part Number |
| ALEXANDER DENNIS | 658558 |
| MACK | 6300-4324210120 |
| VOLVO | WAB4324210120 |
Accessories & Complements
| Part Number | Description |
| 4324070120 | Silencer |
| 4324209232 | Kit: Cartridge |
| 8946004512 | Cable |
Repair Kits
| Part Number | Description |
| 4324100052 | Kit: Valve |
| 4324109242 | Kit: Plunger |
| 4324109402 | Kit: Exhaust + Charging Valve |
| 4324130752 | Kit: Plunger |
| 4324139342 | Kit: Valve Body |
| 4324209202 | Kit: Heater |
