Relay Valve 3/2
Specifications
| Specification | Value |
| Distance between bolts | 75x75 mm |
| Electrical connection | Bayonet DIN 72585 1A-2.1-Sn/K2 |
| Max. operating pressure | 10.2 bar |
| Mounting | 4x M8 |
| Port thread 1 | M22 x 1.5 JED-388 |
| Port thread 2 | M22 x 1.5 JED - 152 |
| Port thread 3 | Exhaust |
| Port thread 41 | M16 x 1.5 JED-388 |
| Port thread 42 | M16 x 1.5 JED-388 |
| Port thread 43 | M16 x 1.5 JED-388 |
| Protection class | IP 66, IP 69K |
| Temperature range | -40°C to +80°C |
| Thread | Voss 230 |
| Voltage | 24 V |
| Size (mm x mm x mm) | 151 x 101 x 132 |
| Weight (kg) | 1.158 |
| Weight (lb) | 2.5529 |
Cross References
| Replaces | Part Number |
| Evobus | A0054292344 |
| Mercedes-Benz | 54292344 |
| Mercedes-Benz | A0054292344 |
