Solenoid Valve 3/2 Specifications Specification Value Electrical connection Bayonet DIN 72 585 A1-2.1-Sn/K2 Exhaust 4.0 mm Max. operating pressure 13.0 bar Multi nominal diameter 4 mm Nominal diameter 4.0 mm...
Solenoid Valve 3/2
Specifications
| Specification | Value |
| Electrical connection | Bayonet DIN 72 585 A1-2.1-Sn/K2 |
| Exhaust | 4.0 mm |
| Max. operating pressure | 13.0 bar |
| Multi nominal diameter | 4 mm |
| Nominal diameter | 4.0 mm |
| Port threads | M12 x 1.5 (Ports 1, 2, 3) |
| Protection class | IP 6K9K, IP 6K7 |
| Rated current | 690 mA |
| Temperature range | -40°C to +80°C |
| Type | Normally open |
| Voltage | 24 V |
| Size (mm x mm x mm) | 126 x 62 x 40 |
| Weight (kg) | 0.608 |
| Weight (lb) | 1.3404 |
Cross References
| Replaces | Part Number |
| Alexander Dennis | 661425 |
| Doll | 7.10E+06 |
| Hyundai | 594307K000 |
| Hyundai | 59430 7K000 |
| Irisbus | 41026588 |
| Iveco | 4.10E+07 |
| Krone | 5.15E+08 |
| Otokar | AIF1913 |
| Scania | 1934971 |
| Schwarzmaeller | 8.36E+04 |
| Tirsan | 21151103312 |
| VDL | 4.11E+07 |
