Brake Signal Transmitter - 2
Specifications
| Specification | Value |
| Distance between holes | 118x182 mm |
| Electrical connection | 2x Bayonet DIN 72585 A1-4.1-Sn/K1 |
| Max. operating pressure | 10.0 bar |
| Mounting | 3x Ø 9.0 mm |
| Multi nominal diameter | 6.0 / 5.0 mm |
| Pedal angle | 46° |
| Port thread 11 | M22 x 1.5 JED - 388-4 |
| Port thread 12 | M16 x 1.5 JED - 388-4 |
| Port thread 21 | M22 x 1.5 JED - 388-4 |
| Port thread 22 | M16 x 1.5 JED - 388-4 |
| Port thread 3 | Silencer |
| Protection class | IP 66, IP 69K |
| Stroke | 22.2 mm |
| Temperature range | -40°C to +80°C |
| Voltage | 9 to 32 V |
| Size (mm x mm x mm) | 347 x 215 x 139 |
| Weight (kg) | 3.192 |
| Weight (lb) | 7.0371 |
Cross References
| Replaces | Part Number |
| Foton | 1.61294E+12 |
| Iveco | 5801546260 |
| King Long | 235400003 |
| Otokar | 16H1208516AA |
| Solaris | 1102408020 |
| VDL | 7.59E+08 |
| VDL | 30016603 |
Repair Kits
| Part Number | Description |
| PSV/69/297 | Kit: Pedal Cover |
