Tristop Cylinder 24/24

Specifications
Specification Value
Bolt lengths 43.0 mm
Bolt threads M16 x 1.5
Distance between bolts 120.6 mm
Max. operating pressure 10.2/8.5 bar
Opposite 925 481 150 0
Output force m 11950 N
Port thread 11 M22 x 1.5 JED - 388
Port thread 12 M22 x 1.5 JED - 388
Port threads M22 x 1.5
Push-rod length 15 mm
Push-rod thread Ball R8
Release pressure 6.1 bar
Return-spring force 220 N
Stroke 64/64 mm
Temperature range -40°C to +80°C
Total length 292.0 mm
Type 24/24
Type of operation Disc
Size (mm x mm x mm) 410 x 197 x 198
Weight (kg) 9.469
Weight (lb) 20.876
Cross References
Replaces Part Number
DAF 1686002
DAF 1365122
FAW 3530020A4A
Mercedes-Benz A0204203018
Repair Kits
Part Number Description
PSV/74/706 Kit: Diaphragm + Spring
Accessories and Complements
Part Number Description
PSV/93/044 Hexagon Nut DIN934-M16x1,5
