ECAS ECU Specifications Specification Value Connector Pins X1 = 18, X2 = 15, X3 = 9 Distance Between Holes 112 x 122 mm Mounting 3 x Ø 7.5 mm Protection...
ECAS ECU
Specifications
| Specification | Value |
| Connector Pins | X1 = 18, X2 = 15, X3 = 9 |
| Distance Between Holes | 112 x 122 mm |
| Mounting | 3 x Ø 7.5 mm |
| Protection Class | IP 30 (IEC 529) |
| System | ECAS 6x2 BUS CAN 2 |
| Temperature Range | -40°C to +75°C |
| Voltage | 24 V |
| Size (mm x mm x mm) | 126 x 134 x 40 |
| Weight (kg) | 0.285 |
| Weight (lb) | 0.62832 |
Cross References
| Replaces | Part Number |
| Hyundai | 95600 8K300 |
| Kenworth | S4461702270 |
| KIA | 956008K300 |
| Mack | 6300-4461702270 |
| Meritor | S4461702270 |
| Peterbilt | S4461702270 |
| Volvo | WAB4461702270 |
