Foot Brake Valve
Specifications
| Specification | Value |
| Actuation | 4613107962 |
| Basic valve | 4613074190 |
| Calculated Volume (dm³) | 11.52 |
| Distance between holes | 80x180 mm |
| Electrical connection | ITT Cannon 4-pin |
| Exhaust | Flap |
| Max. operating pressure | 8.0 bar |
| Mounting | 3x Ø 9.5 mm |
| Nominal diameter | 12.0 mm |
| Pedal angle | 20° |
| Port thread 11 | M22 x 1.5 |
| Port thread 12 | M22 x 1.5 |
| Port thread 21 | M22 x 1.5 |
| Port thread 22 | M22 x 1.5 |
| Predominance | 0.25 bar |
| Temperature range | -40°C to +80°C |
| Size (mm x mm x mm) | 300 x 320 x 120 |
| UPC | 193133301974 |
| Weight (kg) | 3.89 |
| Weight (lb) | 8.576 |
Cross References
| Replaces | Part Number |
| Alexander Dennis | 650353 |
| DAF | 1518771 |
| Iveco | 42012262 |
| Iveco | 42019663 |
| Iveco | 42190492 |
| Leyland Daf | ACU6563 |
| MAN | 81521306049 |
| MAN | 81521306051 |
| MAN | 81521306063 |
| MAN | 81521306092 |
| MAN | 81521309049 |
| Neoplan | 1.10E+12 |
| Neoplan | 81521306063 |
| Renault | 5000590993 |
| Van Hool | 637206440 |
